Cleanroom Class 100 Nitrile Gloves 百级净化间丁晴手套 CN-100D
Features:
&61623Manufactured from high quality Acrylonitrile-Butadiene Rubber NBR synthetic co-polymer
&61623Resistance wide range of solvent chemicals
&61623Excellent sensitivity, superior strength and flexibility
&61623Accelerator free, sulfur free, Itching Free
特点:
&61623由的丁腈橡胶（NBR）合成共聚物制成
&61623耐多种化学品溶剂
&61623优越的灵敏度，高强度，高弹性
&61623不使用添加剂，无硫化过程，不致痒
Process :
&61623Laundered with 0.2 micron filters using 18.2 Mohm EDI water system
&61623Inspection and packed in Clean-room Class 100/ ISO 5
过程:
&61623使用高纯净水18.2 Mohm, 0.2um过滤膜系统洗涤
&61623在百级净化间检查，包装
Applications:
&61623Critical Cleanroom Environment, Semiconductor Industries, Flat Panel Displays
应用:
&61623广泛的应用于净化环境, 半导体行业, 平面显示器等行业
Product Information 产品信息:
1.Cleanliness 洁净度
TEST ITEM SPECIFICATION
Particle CountsOrbital shaker, 0.5um & larger 1000 counts/cm2
Traceable Ions Fluoride F N/A
Chloride Cl 0.1mg/g
Nitrite NO2 N/A
Bromide Br N/A
Nitrate NO3 0.2mg/g
Phosphate PO4 N/A
Sulfate SO4 0.02mg/g
Total Anion 0.35mg/g
Non-Volatile Residue IPA/Hexane 20mg/g
FT-IR Test for major organic contaminants No Silicone oil, No Amide & No DOP
Tested in accordance to Seagate Method—Doc.Number:35344-001 Rev.P
2. Dimensions 尺寸Ref Doc: ASTM D3578/D6319
Glove Size 12”
12”手套尺寸 Palm Width
手掌宽 mm Length
长度 mm Thickness
厚度mm
Small 小码 S 85 + 5 min 290 0.06
Medium 中码M 95 + 5 min 290 0.06
Large 大码 L 105 + 5 min 290 0.06
3. Physical Properties 物理性质Ref Doc: ASTM D6319/D412
Strength Elongation强度/伸长率 Before Aging老化前 After Aging老化后
Tensile Strength拉伸强度 MPa Min 14 min 14
Ultimate Elongation 断裂伸长率% Min 500 min 400
4. ESD Properties防静电性质Ref Seagate Doc: ST1248 Rev. C
Surface Resistivity表面电阻 ohms/square Maximum 1010
Static Decay衰减时间sec Maximum 2
Triboelectric charge摩擦电压 volts Maximum 20
5. SEM/EDX Test表面电镜测试 Ref Seagate Doc: 35366-001 Rev. H
Item项目 SPECIFICATION规格
MgSiO counts/cm2 50
6. Copper Strip Test铜腐蚀性 : No Discoloration无变色
7. Quality Assurance保证 : Manufactured under ISO9001:2008 Quality System and ISO14001:2004 Environment System/公司通过 ISO9001:2008 及ISO14001:2004体系
8. Packaging 包装方式 : 100 pieces of gloves per double poly-bags
10 bags per carton 100只每包，双袋包装，10包每箱
