“脚踏板设备博世杰生产线”产品详情描述：
"Foot pedal production line equipment Bosch jie" product details deion:
GY180脚踏板全自动成型设备构成及生产工艺流程
5.1.1 全自动冲孔/成型设备构成（见示意图）（具体基础图另行提供）
5.1.2 脚踏板全自动冲孔/成型设备生产工艺流程
放料校平一体机→伺服送料 → 冲孔→ 成型→ 切断→出料
脚踏板成型机设备
5.2主要设备结构、性能概述
5.2.1 放料校平一体机
放料机校平一体机技术参数：
板料宽度：≤200 mm；材料厚度≤2.5mm；
料卷内径：φ508mm； 内径涨缩范围ф480-520 mm；
料卷***大外径:φ1200mm承载重量：≤4T
结构特点：
a.放料架与校平机一体，不占空间，操作简单，采用变变径托料装置方便装料及缷料
b.整机采用整体钢构机体，具有结构坚固，运行平稳，占地少，省空间。
c.滚轮经热处理淬火HRC58度后，镀铬再研磨，性强。
Foot pedal molding machine equipment
GY160 pedal fully automatic molding equipment composition and production process
5.1.1 automatic punching/molding equipment composition see diagram subject to provide concrete foundation drawing
5.1.2 the pedals fully automatic punching/molding equipment production process
Feeding leveling machine to servo feed to punching, forming, cutting, discharging
Foot pedal molding machine equipment
5.2 the main equipment structure, performance overview
5.2.1 feeding leveling machine
Feeding leveling all-in-one machine technical parameters:
Sheet metal width: 200 mm or less Material thickness of 2.5 mm or less
Material inside diameter: 508 mm Inside diameter range increases and ф 480-520 - mm
Material: * * * big diameter phi 1200 mm Load weight: 4 t or less
Structure features:
A. feeding frame and leveling machine, does not occupy a space, the operation is simple, using the change diameter feeding device convenient charging and material handling
B. the whole machine adopts whole steel structure body, with solid structure, smooth operation, covering less, save space.
After heat treatment quenching HRC58 degrees c. roller, chrome plated regrinding, strong durability.
