Model Torque Range Hand force at Max.Torque Effective Lgth. Overall Lgth. Weight approx Standard Accessories Interchangeable Heads
Min.-Max. Resolution (1 digit)
S.I. S.I. Metric American S.I. Metric American N mm in. mm in. kg lb.
CEM10N3X8D N.m
2-10 kgf.cm
20-100 in.lbs
20-90 N.m
0.01 kgf.cm
0.1 in.lbs
0.1 48.1 208 8 3/16 212 8 3/8 0.46 1 QH8D Battery Charger BC-3-100
100V
or
BC-3-200
220V (SH,RH,QH,HH) 8D
CEM20N3X10D 4-20 40-200 36-180 0.02 0.2 0.2 92.2 217 8 9/16 214 8 7/16 0.47 1 1/16 QH10D (SH,RH,QH,HH, DH) 10D
CEM50N3X12D 10-50 100-500 100-450 0.05 0.5 0.5 196.9 254 10 282 11 1/8 0.58 1 1/4 QH12D (SH,RH,QH,RQH, HH,DH) 12D
CEM100N3X15D 20-100 200-1000 200-900 0.1 1 1 275.5 363 14 5/16 384 15 1/8 0.63 1 3/8 QH15D (SH,RH,QH,RQH, HH,DH,FH) 15D
CEM200N3X19D 40-200 400-2000 ft.lbs
30-150 0.2 2 ft.lbs
0.2 428.3 467 18 3/8 475 18 11/16 0.78 1 3/4 QH19D (SH,RH,QH,RQH, HH,DH,FH) 19D
CEM360N3X22D 72-360 720-3600 52-260 0.4 4 0.4 498.6 722 28 7/16 713 28 1/16 1.13 2 1/2 QH22D (SH,RH,QH,RQH, HH,DH,FH) 22D
CEM500N3X22D 100-500 kgf.m
10-50 72-360 1 kgf.m
0.05 0.5 549.5 910 35 13/16 949 37 3/8 4.0 8 13/16
CEM850N3X32D 170-850 17-85 124-620 1 0.1 1 608 1398 55 1/16 1387 54 5/8 5.14 11 3/8 QH32D (SH,
