动臂长度Boom length 3030mm
斗臂长度Arm length 1860mm
挖掘距离Maximum Digging Reach 6000mm
挖掘深度Maximum Digging Depth 3580mm
挖掘力Maximum Digging Force 45KN
挖掘高度Maximum Digging Height 5400mm
卸载高度Maximum Dumoing Height 4000mm
小回转半径Minmun Platform Tail tumying Radius 1700mm
外型尺寸DIMENSIONS
机高Wheel base 2550mm
平面宽Width of platform 2000mm
运输状态斗杆外缘至回转减速机距离
Distance from the arm tl rotate machie 3600mm
履带宽Width of crawler 400mm
轮距track 2060mm
(总长×总宽×总高)运输状态
(long×wide×high)travelposition 5200mm×2100mm×2650mm
配重离地间隙Ground Clearance of Counterweight 730mm
小离地间隙Minmun Ground Clearance 360mm
技术性参参数THECHNICAL PERFORMANCE AND SPECIFICATION
旋转角度 angle of rotation 360°
整机重量 Machine werght 6000kg
发动机型号 Enginge type SL4100/4105ABK
液压系统工作压力 Hydraulic system Working pressure 19.5Mpa
额定功率 Rated Power 47.7kw
行驶速度(低/高)Rate of travel/travel speed(Low/High) 0-2.5km/h
牵引力Max hauling force 60KN
爬坡度 Gradeability 30°
全回转时间 Full circle swinging time 5.5s
挖掘斗容 Volume of bucket 0.2-0.3m³
回转过载压力 Revolution overdrive pressure 11mPa
燃油量 FQT Fuel Quantity ≥4L/H
燃油箱容量 Capacity of the fuel tank 130L
液压油容量 Hydraulic Tank Capacity 100L
